| Typ | adapters & contact bridges | ||
| operating voltage ac max. | 48 v dc | ||
| electrical connection 1, type | plug | ||
| electrical connection 1, number of poles | 4-pin | ||
| cable exit | straight | ||
| electrical connection 2, type | 2 x open cable ends | ||
| number of wires | 4 | ||
| Kabellänge | 2 m | ||
| min. ambient temperature | -40 °c | ||
| max. current | 4 a | ||
| cable-Ø | 4.3 mm | ||
| mounting screw tightening torque | 0.8 nm | ||
| Gehäusematerial | polyurethane |
| cable | with cable | ||
| operating voltage dc, max. | 48 v ac | ||
| electrical connection 1, thread size | m12x1 | ||
| electrical connection 1, coding | a-coded | ||
| cable exit angle | 180° | ||
| electrical connection 2, number of poles | 3-pin | ||
| Shielding | unshielded | ||
| Schutzklasse | ip67 | ||
| max. ambient temperature | 80 °c | ||
| wire cross-section | 0.34 mm² | ||
| electrical connection 3, number of poles | 3-pin | ||
| Gewicht | 0.122 kg |
