| Funktion | change-over contact (mechanical) | ||
| mounting orientation | any | ||
| operating pressure max | 16 bar | ||
| compressed air connection | Ø 5x1,5 | ||
| max. ambient temperature | 80 °c | ||
| max. medium temperature | 80 °c | ||
| measurement | relative pressure | ||
| operating voltage dc, max. | 125 v dc | ||
| operational voltage ac, max. | 30 v ac | ||
| protection against overpressure | 80 bar | ||
| shock resistance max. | 15 g | ||
| repetitive precision | ± 2 % | ||
| Hysterese | max. switching pressure difference |
| Typ | diaphragm, spring loaded, adjustable | ||
| operating pressure min | 0.2 bar | ||
| compressed air connection type | flange with o-ring | ||
| min. ambient temperature | -20 °c | ||
| min. medium temperature | -10 °c | ||
| Medium | compressed air, hydraulic oil | ||
| operating voltage dc, min. | 12 v dc | ||
| operating voltage ac, min. | 12 v ac | ||
| switching element | microswitch (input/output) | ||
| Max. Schaltfrequenz | 100/min. | ||
| Schwingfestigkeit | 10 g (60 - 500 hz) | ||
| switching point | adjustable |
