| compressed air connection | g 1/8 | ||
| Diameter | 100 mm | ||
| air consumption at 5 bar | 228 l/min | ||
| working pressure max | 6 bar | ||
| max. ambient temperature | 60 °c | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| Gehäusematerial | aluminum | ||
| nozzle material | stainless steel | ||
| seal material | nitrile butadiene rubber |
| lifting force at 5 bar | 46 n | ||
| Typ | bernoulli principle | ||
| working pressure min. | 1 bar | ||
| min. ambient temperature | 5 °c | ||
| Medium | compressed air | ||
| max. particle size | 40 µm | ||
| material stop | high-temperature material ht1 | ||
| material blanking screw | brass | ||
| Gewicht | 0.3 kg |
