| scraper material | polyurethane | ||
| material stop | steel | ||
| material cylinder tube | steel | ||
| mounting | lock nut | ||
| impact speed min. | 0.02 m/s | ||
| return spring force min. | 30 n | ||
| effective mass me min. | 60 kg | ||
| min. ambient temperature | -20 °c | ||
| Dämpfung | adjustable | ||
| max. energy absorption/stroke | 300 nm | ||
| Mounting thread | m33x1,5 |
| material lock nut | steel | ||
| Werkstoff Kolbenstange | stainless steel | ||
| Gewicht | 0.45 kg | ||
| impact speed max. | 6 m/s | ||
| return spring force max. | 50 n | ||
| effective mass me max. | 2950 kg | ||
| max. ambient temperature | 80 °c | ||
| Medium | oil | ||
| max. energy absorption/hour | 120000 nm | ||
| Hub | 25 mm | ||
| Typ | sa1-ma |
