| port d | nw 5 | ||
| compressed air connection type | internal thread | ||
| nominal flow qn | 210 l/min | ||
| working pressure max | 16 bar | ||
| max. ambient temperature | 90 °c | ||
| max. medium temperature | 90 °c | ||
| delivery unit | 2 piece | ||
| Gehäusematerial | brass | ||
| seal material | acrylonitrile butadiene rubber |
| Anschluss G | m5 | ||
| nominal width nw | 2.7 mm | ||
| working pressure min. | 0 bar | ||
| min. ambient temperature | -10 °c | ||
| min. medium temperature | -10 °c | ||
| Medium | compressed air | ||
| weight per piece | 0.009 kg | ||
| material release bushing | brass | ||
| Material connector | brass |
