| activation | electrically | ||
| switching principle | 5/2 | ||
| working pressure max | 10 bar | ||
| operational voltage ac at 50 hz | 230 v | ||
| voltage tolerance dc | -10% / +10% | ||
| voltage tolerance ac 60 hz | -10% / +20% | ||
| electrical connection type | plug | ||
| actuating control | double solenoid | ||
| pilot | internal | ||
| basic valve with electrical connector | basic valve without coil | ||
| Anschlussart | pipe connection | ||
| can be assembled into blocks | can be assembled into blocks | ||
| min. ambient temperature | -25 °c |
| nominal flow qn | 700 l/min | ||
| working pressure min. | 1.5 bar | ||
| dc operating voltage | 24 v | ||
| operational voltage ac at 60 hz | 230 v | ||
| voltage tolerance ac 50 hz | -20% / +10% | ||
| Handhilfsbetätigung | with detent | ||
| electrical connection size | en 175301-803, form a | ||
| Dichtprinzip | soft seal | ||
| valve type | diaphragm poppet valve | ||
| throttle | with throttle | ||
| blocking principle | plate principle, single base plate principle | ||
| temperature resistance | -25 °c cold-resistant |
