| Typ | adapters & contact bridges | ||
| with led | yellow | ||
| max. ambient temperature | 0 °c | ||
| contact assignment | 2+e | ||
| protective circuit | varistor | ||
| Elektrischer Anschluss | plug | ||
| number of poles | 3-pin | ||
| cable exit | straight | ||
| operational↩voltage | dc | ||
| Gewicht | 0.013 kg |
| Shielding | unshielded | ||
| min. ambient temperature | -10 °c | ||
| max. current | 1 a | ||
| Schutzklasse | ip65 | ||
| Electrical connection 1 | form c | ||
| Electrical connection 2 | m12x1 | ||
| coding | a-coded | ||
| cable exit angle | 180° | ||
| mounting screw tightening torque | 0.6 nm | ||
| Gehäusematerial | polyurethane |
