| Gewicht | 3.21 kg | ||
| oil content of compressed air max. | 1 mg/m³ | ||
| Medium | compressed air | ||
| min. ambient temperature | 0 °c | ||
| working pressure min. | 2 bar | ||
| speed max. | 1.5 m/s | ||
| adjustable end stops | adjustable end stops | ||
| Dämpfungslänge | 12.5 mm | ||
| piston force | 309 n | ||
| Führung | ball rail guide | ||
| Funktionsprinzip | double-acting | ||
| Hub | 200 mm |
| max. particle size | 5 µm | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| max. ambient temperature | 60 °c | ||
| working pressure max | 8 bar | ||
| stroke max. | 1000 mm | ||
| Dämpfung | non-adjustable | ||
| cushioning energy | 3.3 j | ||
| pressure for determining piston forces | 6,3 bar | ||
| easy2combine | capable | ||
| magnetic piston | with magnetic piston | ||
| Anschlüsse | g 1/8 | ||
| piston Ø | 25 mm |
