| Typ | multipole | ||
| operating voltage ac max. | 24 v dc | ||
| cable exit | angled | ||
| Electrical connection 2 | 25-pin | ||
| Shielding | unshielded | ||
| suitable for dynamic laying | suitable for dynamic laying | ||
| min. ambient temperature | -5 °c | ||
| max. current | 3 a | ||
| cable-Ø | 10.1 mm | ||
| Gehäusematerial | metal |
| cable | with cable | ||
| Electrical connection 1 | 25-pin | ||
| cable exit angle | 90° | ||
| number of wires | 25 | ||
| Kabellänge | 3 m | ||
| Schutzklasse | ip20 | ||
| max. ambient temperature | 50 °c | ||
| wire cross-section | 0.25 mm² | ||
| Gewicht | 0.487 kg | ||
| Werkstoff Kabelmantel | polyvinyl chloride |
