| D | 11 | mm | |
| N6 | 15.2 mm ±0.5 | ||
| Drehmoment | 60 | mm | |
| T1 s (Preferred dimension T1S Recommended with tolerances ± 0.75. ) | 28 | mm | |
| nB | 64 |
| H2 | 24,25 | mm | |
| ØS5 | 7 | mm | |
| T1 min | 10 | mm | |
| T1 max | 50 | mm |
| Maschinenschutz | 3,20 | kg | |
| Betriebsbedingungen | Operating conditions | ||
| Zulässige Umgebungstemperatur (min ... max) (Up to 100 °C permissible for short periods. For operation at negative temperatures, please consult us. ) | 0 °C ... +80 °C |
| Lmax | 3.836 | mm | |
| Baugröße | 25 |
