RESIST NR KWD-015-FNS-C0-H-1

149,73 €

verfügbar mit 7 bis 15 Tagen Lieferzeit nach United States

Technische Daten

Area of application: For high rigidity requirements
Significantly reduced frictional oscillations and low friction level, particularly under external load
Maximum precision
Ball Runner Block body made of corrosion-resistant steel as per DIN EN 10088. Version recommended by Rexroth if corrosion protection is required. Fast delivery.
Patented entry zone increases the travel accuracy up to a factor of six

Ball runner block NR with corrosion-resistant steel

Baureihe (R2001)	Flange, normal, standard height R2001
Baugröße (1)	15 size
Vorspannungsklasse (9)	C0 Without preload (clearance)

Genauigkeitsklasse (3)	H Hight Accuracy Level
Dichtungen (31)	LS Low-friction seal without ball chain

Dimensions
Technical data

^a) For O-ring
Size 15: Ø 4 · 1.0 (mm)
Size 20 - 35: Ø 5 · 1.0 (mm)
Open lube port if necessary (see general technical notes and information in the "Maintenance" section).
^b) Recommended position for pin holes (dimension E₄ see general technical notes and information in the "Installation" section)
Rough-drilled holes may be present here from manufacturing. These may be bored open.
^c) Lube nipple, size 15 - 20:
Funnel-type lube nipple DIN 3405-A M3x5, B₂ = 1.6 mm
When using different lube nipples, pay attention to the screw-in depth of 5 mm!
Lube nipple, size 25 - 35:
Hydraulic-type lube nipple DIN 71412-A M6x8, B₂ = 9.5 mm
When using different lube nipples, pay attention to the screw-in depth of 8 mm!
The lube nipple is included in the scope of delivery (not installed).
Connection is possible on all sides.
^d) Sealing plugs may be present here from manufacturing. Remove these prior to mounting.

Industriekomponente	47	mm
A₂	15	mm
B	58.2 mm +0.5
E₁	38	mm
E₃	26	mm
E₉	6,70	mm
H₁	19,90	mm
Dimension H₂ ohne Abdeckstreifen	16,20	mm
K₂	9,60	mm
K₄	3,20	mm
N₂	4,40	mm
S₁	4,30	mm
ØS₅	4,50	mm
Drehmoment	60	mm

A₁	23,50	mm
A₃	16	mm
B₁	39,20	mm
E₂	30	mm
E₈	24,55	mm
H	24	mm
Dimension H₂ mit Abdeckstreifen	16,30	mm
K₁	8	mm
K₃	3,20	mm
N₁	5,20	mm
N₆	10.3 mm ±0.5
S₂	M5
S₉	M2.5x3.5
V₁	5	mm

a_max (If F_comb > 2.8 • F_pr : a_max = 50 m/s²)	500	m/s²
Maschinenschutz	0,20	kg
Betriebsbedingungen	Operating conditions
Zulässige Umgebungstemperatur (min ... max) (Up to 100 °C permissible for short periods. For operation at negative temperatures, please consult us. )	-10 °C ... +80 °C

v_max	5	m/s
Maschinenschutz (Without friction of seal)	0,002 ... 0,003
Baugröße	15
