a)
Lubricating hole M8 x 1 sealed with plastic cap
| Schalter | 5 | ||
| Industriekomponente | 52 | mm | |
| E1 | 50 mm ±0.15 | ||
| E3 | 75 | mm | |
| H | 50 | mm | |
| H1 | 115 | mm | |
| Linie | 101 | mm | |
| Maschinenschutz (Clamped (fastened) in relation to Ø d.) | 38 mm ±0.01 | ||
| N2 | 30 | mm | |
| S1 | M20 | ||
| Ventil | 12 | mm |
| D | 75 | mm | |
| Industriekomponente | 127 | mm | |
| E2 | 62 mm ±0.15 | ||
| E4 | 75 | mm | |
| Toleranz für H (Clamped (fastened) in relation to Ø d.) | + 8 - 16 |
||
| H4 | 45 | mm | |
| L2 | 39 | mm | |
| N1 | 78 | mm | |
| S | 17,50 | ||
| S2 | 12 | ||
| W | 22,10 | mm |
| amax | 150 | m/s² | |
| Maschinenschutz | 3,25 | kg | |
| Losbrechkraft | 22,50 | N | |
| Betriebsbedingungen | Operating conditions |
| vmax | 5 | m/s | |
| FR (Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. ) | 9 | N | |
| Radialluft | Comes clamped to h5 shaft (lower limit) and set to zero clearance | ||
| Zulässige Umgebungstemperatur (min ... max) | -20 °C ... +80 °C |
