a)
Lubricating hole sealed with plastic cap
| D | 62 | mm | |
| Industriekomponente | 108 | mm | |
| E2 | 58 mm ±0.15 | ||
| E4 | 25 | mm | |
| Toleranz für H (Clamped (fastened) in relation to Ø d.) | + 8 - 16 |
||
| H3 | 14 | mm | |
| Linie | 81 | mm | |
| Maschinenschutz (Clamped (fastened) in relation to Ø d.) | 54 mm ±0.01 | ||
| N2 | 26 | mm | |
| S1 | M12 | ||
| Schalter | 4 | ||
| W | 16,80 | mm |
| Industriekomponente | 60 | mm | |
| E1 | 86 mm ±0.15 | ||
| E3 | 90 | mm | |
| H | 45 | mm | |
| H1 | 77 | mm | |
| H4 | 6 | mm | |
| l3 | 30 | ||
| N1 | 44 | mm | |
| S | 10,50 | ||
| S2 | 8 | ||
| Ventil | 10 | mm |
| amax | 150 | m/s² | |
| Maschinenschutz | 1,56 | kg | |
| Losbrechkraft | 18 | N | |
| Betriebsbedingungen | Operating conditions |
| vmax | 5 | m/s | |
| FR (Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. ) | 7,50 | N | |
| Radialspiel der Welle h6 (Clamped (fastened).) | + 35 - 3 |
||
| Zulässige Umgebungstemperatur (min ... max) | -20 °C ... +80 °C |
