R162129371 Bosch Rexroth

REXROTH R162129371 ball runner block resist cr

Name: R162129371 REXROTH
Brand: REXROTH
SKU: 113242-de-eur
Price: 191.1 EUR
Availability: InStock

KWD-025-SNH-C0-H-1

191,10 €

verfügbar mit 7 bis 15 Tagen Lieferzeit nach United States

Finden Sie Ihre passende Kombination! Klicken Sie hier, um passende Führungsleisten für diesen Laufwagen zu entdecken

Technische Daten

Area of application: For restricted space in transverse direction and high rigidity requirements
Higher rigidity than SNS
Maximum precision
Significantly reduced frictional oscillations and low friction level, particularly under external load
Steel Ball Runner Block body with corrosion-resistant coating, matt silver finish, hard chrome plated

Ball runner block Resist CR with corrosion-resistant coating, matt silver finish, hard chrome plated

Baureihe (R1621)	Slimline, normal, high R1621
Baugröße (2)	25 size
Vorspannungsklasse (9)	C0 Without preload (clearance)

Genauigkeitsklasse (3)	H Hight Accuracy Level
Dichtungen (71)	LS Low-friction seal without ball chain

Dimensions
Technical data

^a) For O-ring
Size 15: Ø 4 · 1.0 (mm)
Sizes 25 - 45: Ø 5 · 1.0 (mm)
Open lube port and mount the lubrication adapter if necessary (see general technical notes and information in the "Maintenance" section).
^b) Lube nipple, size 15:
Funnel-type lube nipple DIN 3405-A M3x5, B₂ = 1.6 mm
When using different lube nipples, pay attention to the screw-in depth of 5 mm!
Lube nipple, size 25 - 45:
Hydraulic-type lube nipple DIN 71412-A M6x8, B₂ = 9.5 mm
When using different lube nipples, pay attention to the screw-in depth of 8 mm!
The lube nipple is included in the scope of delivery (not installed).
Connection is possible on all sides.

H₁	33,90	mm
A₁	24	mm
A₃	12,50	mm
B₁	57,80	mm
E₂	35	mm
E₉	15,50	mm
Dimension H₂ mit Abdeckstreifen	24,45	mm
K₁	17,45	mm
K₃	9,50	mm
N₃	9	mm
S₂	M6
S₉	M3x5
V₁	7,50	mm

Industriekomponente	48	mm
A₂	23	mm
B	86.2 mm +0.5
E₁	35	mm
E₈	38,30	mm
H	40	mm
Dimension H₂ ohne Abdeckstreifen	24,25	mm
K₂	18,60	mm
K₄	9,50	mm
N₆	15.2 mm ±0.5
ØS₅	7	mm
Drehmoment	60	mm

a_max (If F_comb > 2.8 • F_pr : a_max = 50 m/s²)	500	m/s²
Maschinenschutz	0,60	kg
Betriebsbedingungen	Operating conditions
Zulässige Umgebungstemperatur (min ... max) (Up to 100 °C permissible for short periods. For operation at negative temperatures, please consult us. )	-10 °C ... +80 °C

v_max	5	m/s
Maschinenschutz (Without friction of seal)	0,002 ... 0,003
Baugröße	25
