| T1 min | 13 | mm | |
| F5 | 13 | mm | |
| D | 11 | mm | |
| N6 | 15.2 mm ±0.5 | ||
| Drehmoment | 60 | mm | |
| T1 max | 50 | mm |
| F4 Mit Abdeckstreifen | 8,20 | mm | |
| F6 | 2 | mm | |
| Dimension H2 mit Abdeckstreifen (with cover strip 0.2 mm) | 24,45 | mm | |
| ØS5 | 7 | mm | |
| T1 s (Preferred dimension T1S Recommended with tolerances ± 0.75. ) | 28 | mm | |
| nB | 64 |
| Maschinenschutz | 3,20 | kg | |
| Betriebsbedingungen | Operating conditions | ||
| Zulässige Umgebungstemperatur (min ... max) (Up to 100 °C permissible for short periods. For operation at negative temperatures, please consult us. ) | 0 °C ... +80 °C |
| Lmax (For accuracy classes P, one-piece Ball Guide Rail lengths are available on request for size 25 up to 5816 mm and for size 30 - 35 up to 5836 mm. ) | 3.836 | mm | |
| Baugröße | 25 |
