| Baugröße | 50 x 5R x 3,5 50 x 10R x 6 50 x 12R x 6 50 x 16R x 6 50 x 20R x 6,5 50 x 25R x 6,5 50 x 30R x 6,5 50 x 40R x 6,5 |
||
| Lochmuster | BB1 | ||
| Industriekomponente | 95 | mm | |
| D1 | 75 | mm | |
| E1 | 110 mm ±0.15 | ||
| H | 48 mm ±0.01 | ||
| H2 | 12 | mm | |
| S | 17 | ||
| T1 | 30 | mm | |
| T2 | 17 | mm |
| Masse | 5,63 | g | |
| Zylinderschraube mit Innensechskant | M16 | ||
| B | 70 mm ±0.01 | ||
| D6 | 93 | mm | |
| E2 | 45 mm ±0.15 | ||
| H1 | 96 | mm | |
| N | 34 | mm | |
| S1 | M20 | ||
| S2 | M10 | ||
| Spannlänge | 75 | L |
