1)
Countersink for O-ring 7 x 1.5
| Baugröße | 32 x 5R x 3,5 32 x 10R x 3,969 32 x 20R x 3,969 3 x 32R x 3,969 |
||
| Zylinderschraube mit Innensechskant (for bolting from below) | M10 | ||
| B | 50 mm ±0.01 | ||
| E1 | 75 | mm | |
| H | 49 mm ±0.01 | ||
| H2 | 9 | mm | |
| S | 10,50 | ||
| T1 | 18 | mm | |
| T3 | 131 | mm |
| Masse | 2,31 | g | |
| Industriekomponente | 150 | mm | |
| ØD1 | 50 | H<sub>6</sub> | |
| E2 | 100 | mm | |
| H1 | 80 | mm | |
| HA5 | 16 | ||
| S1 | M12 | ||
| T2 | 15 | mm | |
| Spannlänge | 66 | L |
