| D | 62 | mm | |
| D1 | 66.5 mm +0.8 | ||
| e | 78 mm ±0.25 | ||
| L1 | 36 | mm | |
| S | 11 | ||
| W | 22 | mm |
| B (Tolerance ISO 8062-3 - DCTG 9.) | 108 | ||
| D2 (Tolerance ISO 8062-3 - DCTG 9.) | 80 | mm | |
| Linie | 80 | mm | |
| L1 | 36 mm | ||
| Ventil (Tolerance ISO 8062-3 - DCTG 9.) | 16 | mm |
| amax | 150 | m/s² | |
| Maschinenschutz | 1,65 | kg | |
| Losbrechkraft | 8 | N | |
| Betriebsbedingungen | Operating conditions |
| vmax (Speeds of up to 5 m/s possible. Service life is limited by heightened wear to plastic parts. Tests have shown total travel from 50 • 105 m to 100 • 105 m without failure. ) | 3 | m/s | |
| FR (Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. ) | 3 | N | |
| Radialspiel der Welle h6 | + 50 + 12 |
||
| Zulässige Umgebungstemperatur (min ... max) | -10 °C ... +80 °C |
