REXROTH R107222000 linear-set

LSASE-M-20-DD

173,40 €
verfügbar mit 7 bis 15 Tagen Lieferzeit nach United States

Technische Daten

  • Lightweight precision housing (aluminum)
  • Standard Linear Bushing
  • Secured by grooved taper pin
  • External seals
  • No lube port

Typ (LSAS) Linear sets Side opening, adjustable, R1072
Form (E) Adjustable
Baureihe (M) Standard linear bushing
Wellendurchmesser (20) 20 Shaft diameter
Dichtungen (DD) With two seals
D 32 mm
E1 22 mm ±0.15
E3 33 mm
H 30 mm
H1 60 mm
Linie 54 mm
N1 42 mm
S (Cylinder bolts ISO 4762-8.8) 8,40
S2 (Pin hole centering.) 6
Ventil 5 mm
Industriekomponente 60 mm
E2 30 mm ±0.15
E4 42 mm
Toleranz für H (Clamped (fastened) in relation to Ø d.) + 5
- 19
H4 22 mm
Maschinenschutz (Clamped (fastened) in relation to Ø d.) 17 mm ±0.01
N2 15 mm
S1 M10
Schalter 2,50
W (Minimum size in relation to Ø d.) 10 mm
amax 100 m/s²
Maschinenschutz 0,45 kg
Losbrechkraft 16 N
Betriebsbedingungen Operating conditions
vmax 2,50 m/s
FR (Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. ) 6 N
Radialluft Comes clamped to h5 shaft (lower limit) and set to zero clearance
Zulässige Umgebungstemperatur (min ... max) -10 °C ... +80 °C
173,40 €
Lagerbestand verfügbar
Teilenummer R107222000
Hersteller REXROTH
Menge Stückpreis
1+ 173,40 €
