| Industriekomponente | 60 | mm | |
| D | 20 | mm | |
| H (In relation to nominal shaft dimension "d") | 30 mm ±0.01 | ||
| H4 | 16 | mm | |
| N1 | 25 | mm | |
| Schalter | 4 | ||
| S1 | M10 |
| B | 30 | ||
| e | 42 mm ±0.15 | ||
| H1 | 51 | mm | |
| Maschinenschutz (In relation to nominal shaft dimension "d") | 30 mm ±0.01 | ||
| N2 | 22 | mm | |
| S (Fixing screws ISO 4762-8.8) | 8,40 | ||
| Ventil | 5 | mm |
| Maschinenschutz | 0,18 | kg |
| MA | 16 | Nm |
