| Industriekomponente (Tolerance ISO 8062-3 - DCTG 11.) | 74 | mm | |
| B (Tolerance ISO 8062-3 - DCTG 11.) | 25 | ||
| e | 60 mm ±0.15 | ||
| H1 (Tolerance ISO 8062-3 - DCTG 11.) | 58 | mm | |
| S (Cylinder bolts ISO 4762-8.8) | 6,60 |
| A1 (Tolerance ISO 8062-3 - DCTG 11.) | 38 | mm | |
| D | 25 | mm | |
| H (In relation to nominal shaft dimension "d") | 35 mm ±0.01 | ||
| Schalter | 4 | ||
| Ventil (Tolerance ISO 8062-3 - DCTG 11.) | 9 | mm |
| Maschinenschutz | 0,37 | kg |
