REXROTH R065825534 COMPACT-KUGELBUECHSE

Name: R065825534 REXROTH
Brand: REXROTH
SKU: 29598-de-eur
Price: 107.05 EUR
Availability: InStock

KBC-30-DD-RT-NR-G

107,05 €

verfügbar mit 7 bis 15 Tagen Lieferzeit nach United States

Technische Daten

Low-cost Linear Bushing for general requirements
Small outer dimensions and highly compact construction
High dynamic load rating and long service life due to hardened segmental load-bearing plates with ball conformity in the track.
Reduced radial clearance for applications where minimal-clearance bearings with an H7 bore are desired
Initial lubrication with Dynalub 510

Radialluft (RT)	Reduced radial clearance (eLINE linear bushing)
Lineare Buchsenversion (NR)	Stainless steel
Schmierung der Linearbuchse (G)	Greased

Baureihe		Compact (C)
Maximale dynamische Tragfähigkeit Cmax		2700 N
Maximal zulässige lineare Geschwindigkeit vmax		5 m/s
Außendurchmesser d		40 mm
Zulässige Umgebungstemperatur		-10 °C ... +80 °C
Fußnote maximale dynamische Tragfähigkeit Cmax		The dynamic load capacities are based on a total travel of 100,000 m. When based on 50,000 m, the C values in the table are to be multiplied by 1.26.
Losbrechkraft		6 N
Fußnote minimale statische Tragfähigkeit C0min		The load ratings are based on a total travel of 100, 00 m. When based on 50 000 m, the values in the table need to be multiplied by 1.26.

Dynamische Tragzahl C		2700 N
Max. Beschleunigung amax		150 m/s²
Länge Kugelbüchse		50 mm
Statische Tragzahl C0		2230 N
Fußnote Reibkraft FR		Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication.
Fußnote minimale dynamische Tragfähigkeit Cmin		The dynamic load capacities are based on a total travel of 100,000 m. When based on 50,000 m, the C values in the table are to be multiplied by 1.26.
Fußnote maximale statische Tragfähigkeit C0max		The load ratings are based on a total travel of 100, 00 m. When based on 50 000 m, the values in the table need to be multiplied by 1.26.
