| Gewicht | .62322 lb | ||
| Anschluss | power supply / output connection: 8p connector, sensor connection: 4p connector (e-con) | ||
| status led?s | illuminates when output is on out1: red | ||
| temperature characteristics | ?2% f.s. or less (0 to 50c, based on 25c) | ||
| linearity note 4) | ?5% f.s. or less | ||
| Hysterese | hysteresis mode: variable (can be set from 0), window comparator mode: fixed (3-digits) | ||
| sensor input | 1 to 5 vdc (input impedance: approx. 800k ) | ||
| power supply voltage for sensor | same as [power supply voltage] | ||
| Versorgungsspannung | 24 vdc (ripple ?10% or less) (with power supply polarity protection) | ||
| note 1)display units | accumulated flow | ||
| minimum set unit note 1) | 0.05 l/min | ||
| flow rate measurement range note 1) | 0.25 to 4.50 l/min | ||
| Baureihe | pf2d200/201 |
| Material | housing: pbt, display: pet, backside rubber: cr | ||
| resistance | noise resistance | ||
| display method | for measured value display: 4-digits, 7-segment led (orange) for channel display: 1-digit, 7-segment led (red) | ||
| repeatability note 4) | ?3% f.s. or less | ||
| response time note 4) | 1s or less | ||
| output note 3)specifications | output protection | ||
| power supply current for sensor note 2) | max. 110 ma (however, the total current for the 4 inputs is 440 ma maximum or less.) | ||
| Stromaufnahme | 55 ma or less (not including the current consumption of the sensor) | ||
| accumulated flow range note 1) | 0 to 999999 l, 0 to 999999 gal(us) | ||
| accumulated pulse flow rate exchange value (pulse width: 50ms) note 1) | 0.05 l/pulse | ||
| set flow rate range note 1) | 0.25 to 4.50 l/min | ||
| applicable flow rate sensor | pf2d504- -1 |
