NORGREN P68F-8GH-PPA olympian plus soft start dump valve

Name: P68F-8GH-PPA NORGREN
Brand: NORGREN
SKU: 790112-de-eur
Price: 1259.22 EUR
Availability: SoldOut

1.259,22 € ~~1.794,39 €~~ -29%

Begrenzter Lagerbestand nur auf Anfrage erhältlich

Technische Daten

Actuation Type	solenoid pilot / spring return
max. Druck	3 ... 10 bar

Versorgungsspannung	24vdc, 4.5w

actuation		solenoid pilot / spring return
body		zinc alloy
connector plug		3pin plug with cable gland
elastomers		synthetic material
flow flow dm3sec		147 dm3/sec
gauge port		rc1/8
Handhilfsbetätigung		button (shrouded)
maximum inlet pressure pressure bar		10 bar
operating pressure pressure bar min to max range		3 ... 10 bar
operating temperature f temperature fahrenheit min to max range		-4 ... 149 °f
operation		3/2
Anschlussgröße		g1
range		p68f
voltage		24vdc, 4.5w

air pilot ports		g1/4
bonnet		zinc alloy
data performance shelf life		3 years
exhaust port		g1
flow flow dm3secbar		147 dm3/(s.bar) dm3/sec
inner parts		steel
maximum inlet pressure imperial pressure psi		145 psig
Medium		compressed air
operating pressure psi pressure psi min to max range		44 ... 145 psi
operating temperature temperature celsius min to max range		-20 ... 50 °c
operator		32mm solenoid with manual lockout
product style		plug-in
Baureihe		olympian plus
