| ra max - Max fillet radius | 1 mm | ||
| dc min - Min inner ring GO diameter | 67 mm | ||
| BSF - Characteristic rolling element frequency | 6,898 Hz | ||
| BPFI - Characteristic inner ring frequency | 8,565 Hz | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Grease lubrication limit speed | 7600 tr/min | ||
| Cu - Fatigue limit load | 6,2 kN | ||
| C - Dynamic load | 48 kN | ||
| r1s - Min fillet radius | 1,1 mm | ||
| d1 - IR flange outer diameter | 64,6 mm | ||
| E - Upper roller diameter | 80,4 mm |
| Da max - Max shoulder diameter OR | 83,5 mm | ||
| da min - Min shoulder diameter IR | 56,5 mm | ||
| FTF - Characteristic cage frequency | 0,429 Hz | ||
| BPFO - Characteristic outer ring frequency | 6,435 Hz | ||
| Tmin - Min operating temperature | -40 °C | ||
| Nlim - Oil lubrication limit speed | 9000 tr/min | ||
| C0 - Static load | 51 kN | ||
| Radial clearance class | CN | ||
| rs - Min fillet radius | 1,1 mm | ||
| F - Under roller diameter | 60,4 mm | ||
| Brand | NTN |
