| Außen-Ø | D | 72 | mm |
| Breite | B | 80 | mm |
| Basic static load rating, radial | C0r | 65,000 | |
| Speed on permanent grease lubrication | nD G | 2,600 | |
| Permissible dynamic load outer ring, radial | Fr per | 31,500 |
| Fit diameter of roller stud / stud | d1 | 24 | mm |
| Basic dynamic load rating, radial | Cr | 45,500 | |
| Fatigue load limit, radial | Cur | 8,900 | |
| Permissible static load, radial | F0r per | 62,000 |
| Maximum witdh of thrust washer | B1 | 30,60 | mm |
| Width, outer ring | C | 28 | mm |
| Minimum chamfer dimension | rmin | 1,10 | mm |
| Gewinde | M24X1,5 | ||
| Width of flats | W | 14 | mm |
| Width, eccentric | Be | 22 | mm |
| Bolt/stud length effectively | B2 | 49,50 | mm |
| Protrusion outer ring to thrust washer | C1 | 1,30 | mm |
| Stop diameter of thrust washer | d2 | 44 | mm |
| Thread length | IG | 25 | mm |
| Diameter of eccentric | de | 28 | mm |
| Eccentricity | e | 1 | mm |
| Hersteller | Teilenummer |
|---|---|
| SKF | NUKRE72-A (SKF) |
| SKF | NUKRE72 |
| LI-BE | CFE72ZZ |
| SKF | NUKRE72SK |
