| Bore diameter | d | 110 | mm |
| Breite | B | 53 | mm |
| Chamfer dimension of loose flange ring | F | 132,50 | mm |
| Permissible axial displacement | s | max.3.7 |
| Außen-Ø | d2 | 200 | mm |
| Shoulder diameter of outer ring | D1 | ≈172.48 | |
| chamfer dimension | rmin | min.2.1 |
| Hersteller | Teilenummer |
|---|---|
| FAG | NU2222-E-TVP2 (FAG) |
