| Bore diameter | d | 80 | mm |
| Breite | B | 33 | mm |
| Chamfer dimension of loose flange ring | F | 95,30 | mm |
| Permissible axial displacement | s | max.1.4 |
| Außen-Ø | d2 | 140 | mm |
| Shoulder diameter of outer ring | D1 | ≈121.7 | |
| chamfer dimension | rmin | min.2 |
| Hersteller | Teilenummer |
|---|---|
| FAG | NU2216-E-TVP2 (FAG) |
| FAG | NU2216-E-M1 (FAG) |
