| ra max - Max fillet radius | 2,5 mm | ||
| dc min - Min inner ring GO diameter | 143 mm | ||
| da min - Min shoulder diameter IR | 113 mm | ||
| FTF - Characteristic cage frequency | 0,4 Hz | ||
| BPFO - Characteristic outer ring frequency | 5,196 Hz | ||
| Tmin - Min operating temperature | -40 °C | ||
| Nlim - Oil lubrication limit speed | 3500 tr/min | ||
| C0 - Static load | 425 kN | ||
| Radial clearance class | C3 | ||
| rs - Min fillet radius | 3 mm | ||
| F - Under roller diameter | 127,5 mm | ||
| Brand | NTN |
| Da max - Max shoulder diameter OR | 202 mm | ||
| da max - Small face shoulder max diameter | 125 mm | ||
| BSF - Characteristic rolling element frequency | 4,784 Hz | ||
| BPFI - Characteristic inner ring frequency | 7,804 Hz | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Grease lubrication limit speed | 2900 tr/min | ||
| Cu - Fatigue limit load | 45,2 kN | ||
| C - Dynamic load | 380 kN | ||
| r1s - Min fillet radius | 3 mm | ||
| d1 - IR flange outer diameter | 140,3 mm | ||
| E - Upper roller diameter | 191,5 mm |
