| ra max - Max fillet radius | 2 mm | ||
| dc min - Min inner ring GO diameter | 104 mm | ||
| da min - Min shoulder diameter IR | 89 mm | ||
| FTF - Characteristic cage frequency | 0,432 Hz | ||
| BPFO - Characteristic outer ring frequency | 6,912 Hz | ||
| Tmin - Min operating temperature | -40 °C | ||
| Nlim - Oil lubrication limit speed | 5100 tr/min | ||
| C0 - Static load | 186 kN | ||
| Radial clearance class | C3 | ||
| rs - Min fillet radius | 2 mm | ||
| F - Under roller diameter | 95,3 mm | ||
| Brand | NTN |
| Da max - Max shoulder diameter OR | 131 mm | ||
| da max - Small face shoulder max diameter | 94 mm | ||
| BSF - Characteristic rolling element frequency | 7,217 Hz | ||
| BPFI - Characteristic inner ring frequency | 9,088 Hz | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Grease lubrication limit speed | 4400 tr/min | ||
| Cu - Fatigue limit load | 22 kN | ||
| C - Dynamic load | 163 kN | ||
| r1s - Min fillet radius | 2 mm | ||
| d1 - IR flange outer diameter | 101,2 mm | ||
| E - Upper roller diameter | 125,3 mm |
