FESTO NEDY
35 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO NEDY – Distributor. Finden Sie das passende Produkt durch Filtern mit Connection technology left, field device side, Cable outlet left, Number of pins/wires on the left, Anzeige, Leitungseigenschaft, Cable length left, Cable identification, Connection technology right, controller side und Cable length right.
NEDY Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| NEDY | NEDY-L2R1-V1- - - - | Distributor |
Typcode zur Katalognummer NEDY,
NEDY-L2R1-V1- - - -
| 001 | Series |
|---|---|
| NEDY | Distributor |
| 002 | Distributor type |
| L2R1 | Y-distributor |
| 003 | Circuitry |
| V1 | Standard variant (see circuit diagram, standard) |
| 004 | Connection technology left, field device side |
| A1 | Socket type A, EN 175301-803 |
| B1 | Socket type B, EN 175301-803 |
| B2 | Socket type B, industry standard, 11 mm |
| C1 | Socket type C, EN 175301-803 |
| E1 | Socket type C, industry standard 9.4 mm |
| H1 | Socket connection pattern H |
| LE | Open end |
| M8 | Socket M8x1 A-coded, EN 61076-2-104 |
| M12 | Socket M12x1 A-coded, EN 61076-2-101 |
| Z1 | Socket connection pattern ZB, self-tapping screw |
| Z3 | Socket connection pattern ZC, self-tapping screw |
| Z4 | Socket connection pattern ZC, metric screw |
| 005 | Cable outlet left |
| None | |
| G | Straight |
| R | Rotating |
| W | Angled |
| 006 | Number of pins/wires on the left |
| 2 | 2 |
| 3 | 3 |
| 4 | 4 |
| 5 | 5 |
| 007 | Display |
|---|---|
| None | |
| L | LED signal status, DC |
| P | LED switching state, PNP |
| Z | LED signal status, holding current reduction |
| 008 | Cable characteristic |
| Without cable | |
| U | Suitable for energy chains |
| 009 | Cable length left |
| None | |
| ...L | 0.3 ... 30 m |
| 010 | Cable identification |
| With label holder | |
| N | Without label holder |
| 011 | Connection technology right, controller side |
| LE | Open end |
| M8 | Plug M8x1 A-coded, EN 61076-2-104 |
| M12 | Plug M12x1 A-coded, EN 61076-2-101 |
| 012 | Cable outlet right |
| None | |
| G | Straight |
| W | Angled |
| 013 | Number of pins/wires on the right |
| 3 | 3 |
| 4 | 4 |
| 014 | Cable length right |
| None | |
| ...R | 0.3 ... 30 m |
