FESTO NEBC
92 Produkte
Technische Daten
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO NEBC – Connecting cable for control ers. Finden Sie das passende Produkt durch Filtern mit Product version, Connection technology left, field device side, Cable outlet left, Number of pins/wires on the left, Additional socket functions, Leitungseigenschaft, Cable design, Cable length [m], Cable identification, Type of connector, Connection technology right, control er side, Plug und Number of pins/wires on the right.
NEBC Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| NEBC | NEBC- - - - - | Connecting cable for control ers |
| 001 | Series |
|---|---|
| NEBC | Connecting cable for control ers |
| 002 | Product version |
| Standard | |
| C | Easy-to-clean design |
| 003 | Connection technology left, field device side |
| A1 | Socket type A, EN 175301-803 |
| LE | Open end |
| M8 | Socket M8x1 A-coded, EN 61076-2-104 |
| M12 | Socket M12x1 A-coded, EN 61076-2-101 |
| D8 | M8, D-coded, IEC 61076-2-114 ED1 |
| M9 | M9 |
| D12 | M12, D-coded |
| F12 | M12, Festo-specifi c encoding |
| U1 | USB, type A |
| R3 | RJ45 |
| S1 | Sub-D socket |
| P1 | Fork spring |
| R3Z12 | RJ45 and socket strip 12-pin |
| 004 | Cable outlet left |
| None | |
| G | Straight |
| W | Angled |
| WA | Angled 45° |
| 005 | Number of pins/wires on the left |
| 3 | 3 |
| 4 | 4 |
| 5 | 5 |
| 8 | 8 |
| 9 | 9 |
| 20 | 20 |
| 25 | 25 |
| 006 | Additional socket functions |
| None | |
| HS | With seal |
| 007 | Cable characteristic |
| Without cable | |
| K | Standard |
| E | Suitable for energy chains |
| 008 | Cable design |
| Standard | |
| H | Hybrid cable |
| S | With shielding |
| 009 | Cable length [m] |
| 0.2 | 0.2 |
| 0.25 | 0.25 |
| 0.3 | 0.3 |
| 0.5 | 0.5 |
| 1 | 1 |
| 1.5 | 1.5 |
| 1.8 | 1.8 |
| 2 | 2 |
| 2.5 | 2.5 |
| 3 | 3 |
| 3.2 | 3.2 |
| 5 | 5 |
| 7.5 | 7.5 |
| 10 | 10 |
| 15 | 15 |
| 20 | 20 |
| 25 | 25 |
| 30 | 30 |
| 40 | 40 |
| 50 | 50 |
| 010 | Cable identification |
|---|---|
| With label holder | |
| N | Without label holder |
| 011 | Type of connector |
| Standard | |
| B | Socket |
| S | Plug at both ends |
| SB | Plug/socket |
| SBS | Plug, left socket strip/right plug |
| 012 | Connection technology right, control er side |
| LE | Open end |
| D8 | M8, D-coded, IEC 61076-2-114 ED1 |
| M12 | Plug M12x1 A-coded, EN 61076-2-101 |
| F12 | M12, 4 wires |
| D12 | M12, D-coded |
| RS | Round plug |
| U2 | USB, type B |
| R3 | RJ45 |
| S1 | Sub-D |
| 013 | Plug |
| None | |
| G | Straight |
| W | Angled |
| 014 | Number of pins/wires on the right |
| 3 | 3 |
| 4 | 4 |
| 5 | 5 |
| 8 | 8 |
| 9 | 9 |
| 17 | 17 |
| 25 | 25 |
| 26 | 26 |
