| Bore diameter | d | 17 | mm |
| Width, inner ring | Bi | 14 | mm |
| Basic static load rating, radial | C0r | 11,000 | |
| Limiting speed for grease lubrication | nG Grease | 12,000 |
| Außen-Ø | D | 30 | mm |
| Basic dynamic load rating, radial | Cr | 10,000 | |
| Fatigue load limit, radial | Cur | 2,220 |
| Raceway diameter inner ring | F | 22 | mm |
| Minimum chamfer dimension | rmin | 0,30 | mm |
| Width, outer ring | C | 13 | mm |
