| Brand | SNR | ||
| Carriage version | C | ||
| Baugröße | 30 | ||
| Sealing | SS - End seals on both sides, inner and side seals | ||
| Special options | N - Standard | ||
| Lubricant | A - SNR LUB HEAVY DUTY | ||
| W | 90 mm | ||
| E | 7 mm | ||
| J | 52 mm | ||
| ih | 8,6 mm | ||
| L1 | 103,5 mm | ||
| T1 | 8 mm | ||
| T2 | 5,5 mm | ||
| H3 | M 6 | ||
| C50 | 53,83 kN | ||
| C0 | 88,18 kN | ||
| My | 1,361 kN/m |
| Baureihe | LGB | ||
| Carriage Height | H | ||
| Design type | FE | ||
| Material | Carbon steel | ||
| Lubrication connection | 00 - Conical grease nipple 67° | ||
| H | 42 mm | ||
| W2 | 31 mm | ||
| L - Length | 130,5 mm | ||
| MQ | M 10 | ||
| L | 12 mm | ||
| H2 | M 6 | ||
| N | 11,7 mm | ||
| L2 | 6 mm | ||
| Lx | 5 mm | ||
| C100 | 42,72 kN | ||
| Mx | 1,142 kN/m | ||
| Mz | 1,361 kN/m |
