FESTO LFR
465 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO LFR – Filter regulator. Finden Sie das passende Produkt durch Filtern mit Pneumatischer Anschluss, Ausführung, Funktion, Druckregelbereich, Grade of filtration [μm], Pressure gauge, Function Directly actuated pressure regulator (MICRO, MINI, MIDI), pilot actuated pressure regulator (only MAXI), Baugröße, Service unit combination, Kondensatablass, Temperature range, Display unit und EU certification.
LFR Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| LFR | LFR- - - | Filter regulator |
Typcode zur Katalognummer LFR,
LFR- - -
| 001 | Series |
|---|---|
| LFR | Filter regulator |
| 002 | Pneumatic connection |
| 1/8 | Female thread G1/8 |
| 1/4 | Female thread G1/4 |
| 3/8 | Female thread G3/8 |
| 1/2 | Female thread G1/2 |
| 3/4 | Female thread G3/4 |
| 1 | Female thread G1 |
| N1/2 | Female thread 1/2 NPT |
| N1/4 | Female thread 1/4 NPT |
| 003 | Version |
| D | D series, metal |
| DB | D series, polymer |
| 004 | Function |
| Directly actuated pressure regulator (MICRO, MINI, MIDI), pilot actuated pressure regulator (only MAXI) | |
| DI | Directly actuated pressure regulator with integrated return fl ow function (only MAXI) |
| 005 | Pressure regulation range |
| 16 | 0.5 ... 16 bar |
| 7 | 0.5 ... 7 bar (0.05 ... 0.7 MPa) |
| 12 | 0.5 ... 12 bar (0.05 ... 1.2 MPa) |
| 0.5 ... 12 bar (0.05 ... 1.2 MPa) | |
| 006 | Grade of filtration [μm] |
| 5M | 5 μm |
| 40 μm | |
| 007 | Pressure gauge |
| With pressure gauge | |
| O | Without pressure gauge |
| 008 | Function Directly actuated pressure regulator (MICRO, MINI, MIDI), pilot actuated pressure regulator (only MAXI) |
| Undefined |
| DI | Directly actuated pressure regulator with integrated return fl ow function (only MAXI) |
| 009 | Size |
|---|---|
| MICRO | MICRO Grid dimension (without connecting plates) |
| MINI | Grid dimension 40 mm (without connecting plates) |
| MIDI | Grid dimension 55 mm (without connecting plates) |
| MAXI | Grid dimension 66 mm (without connecting plates) |
| 010 | Service unit combination |
| None | |
| KB | Filter regulator, branching module, on/off valve manually oper- ated |
| KA | Filter regulator, branching module |
| KC | On/off valve manually operated, fi lter regulator |
| KG | On/off valve manually operated, fi lter regulator, on/off valve electrically operated, 24 V DC, soft-start valve pneumatically operated, branching module with pressure switch |
| KF | On/off valve manually operated, fi lter regulator, branching mod- ule with pressure switch |
| KE | Filter regulator, branching module, soft-start valve pneumatical- ly operated |
| KD | Filter regulator, on/off valve electrically operated, 24 V DC, soft- start valve pneumatically operated |
| 011 | Condensate drain |
| Manually rotating | |
| A | Fully automatic |
| 012 | Temperature range |
| None | |
| T3 | -40 ... +80°C |
| T18 | -20 ... +80°C |
| 013 | Display unit |
| Bar/psi/without | |
| MPA | MPa |
| 014 | EU certification |
| None | |
| EX4 | II 2GD |
