PARKER L06A3-90-90N

Name: L06A3-90-90N PARKER
Brand: PARKER
SKU: 761966-de-eur
Price: 310 EUR
Availability: SoldOut

310 €

Begrenzter Lagerbestand nur auf Anfrage erhältlich

Technische Daten

max. Druck	6000 psi, 420 bar
Max. Volumenstrom	47 gal/min, 180 l/min

Dichtung	nitrile
Gewicht	446g

Maximale Betriebstemperatur		+250 °f, +121 °c
standard flow rate setting		17.2-47.8 gal/min, 65-180 l/min
seal material		nitrile
actuation type		interlocking spools
flow rate accuracy		10%
maximum inlet pressure rating		6000 psi, 420 bar
Funktion		flow divider/combiner
for fluid type		mineral-based or synthetic hydraulic fluids
filter efficiency rating		iso 4406 18/16/13, sae class 4
installation torque		74 lb-ft, 100 nm
Minimale Betriebstemperatur		-30 °f, -34 °c

flow rate		47 gal/min, 180 l/min
ratio		50/50
division		mobile systems division europe
maximum flow rate		47 gal/min, 180 l/min
maximum operating pressure		6000 psi, 420 bar
cavity size		c16-4
operation type		automatic
maximum kinematic viscosity		45-2000 ssu (6 to 420 cst)
valve material		all parts steel. all operating parts hardened steel
Betriebstemperatur		-30 to +250 °f, -34 to +121 °c
Gewicht		0.86 lb, 0.4 kg
