| Bore diameter | d | 25 | mm |
| Nominal width | B | 15 | mm |
| Raceway diameter inner ring | F | 42 | mm |
| Width Outer ring | C | 14 | mm |
| Chamfer dimension bore/small side face | r2 | min.0.3 |
| Außen-Ø | d2 | 47 | mm |
| Angle of tilt | α | 2,70 | ° |
| Width Inner ring | B | 15 | mm |
| Chamfer dimension bore/large side face | r1 | min.0.6 | |
| Distance sphere diameter centre - large inner ring side face | s | 0,60 | mm |
