FESTO FRC
202 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO FRC – Service unit. Finden Sie das passende Produkt durch Filtern mit Pneumatischer Anschluss, Ausführung, Druckregelbereich, Grade of filtration [μm], Service unit combination, Pressure gauge, Baugröße, Kondensatablass und Display unit.
FRC Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| FRC | FRC- -D-5M- | Service unit |
| FRC | FRC-1/4-DB-MINI | Service unit |
| FRC | FRC-1/4-DB-MINI- | Service unit |
| FRC | FRC- -D- | Service unit |
Typcode zur Katalognummer FRC,
FRC- -D-5M-
| 001 | Series |
|---|---|
| FRC | Service unit |
| 002 | Pneumatic connection |
| 1/8 | Female thread G1/8 |
| 1/4 | Female thread G1/4 |
| 3/8 | Female thread G3/8 |
| 1/2 | Female thread G1/2 |
| 3/4 | Female thread G3/4 |
| 1 | Female thread G1 |
| 003 | Version |
| D | D series, metal |
| 004 | Pressure regulation range |
| 0.5 ... 12 bar (0.05 ... 1.2 MPa) | |
| 7 | 0.5 ... 7 bar (0.05 ... 0.7 MPa) 0.5 ... 12 bar (0.05 ... 1.2 MPa) |
| 005 | Grade of filtration [μm] |
| 5M | 5 μm |
| 006 | Pressure gauge |
|---|---|
| With pressure gauge | |
| O | Without pressure gauge |
| 007 | Size |
| MINI | Grid dimension 40 mm (without connecting plates) |
| MIDI | Grid dimension 55 mm (without connecting plates) |
| MAXI | Grid dimension 66 mm (without connecting plates) |
| 008 | Condensate drain |
| A | Fully automatic |
| Manually rotating | |
| 009 | Display unit |
| Bar/psi/without | |
| MPA | MPa |
Typcode zur Katalognummer FRC,
FRC-1/4-DB-MINI
| 001 | Series |
|---|---|
| FRC | Service unit |
| 002 | Pneumatic connection |
| 1/4 | Female thread G1/4 |
| 003 | Version |
| DB | D series, polymer |
| 004 | Pressure regulation range |
| 0.5 ... 12 bar (0.05 ... 1.2 MPa) | |
| 7 | 0.5 ... 7 bar (0.05 ... 0.7 MPa) |
| 005 | Grade of filtration [μm] |
|---|---|
| 40 µm | |
| 5M | 5 µm |
| 006 | Size |
| MINI | Grid dimension 40 mm (without connecting plates) |
| 007 | Condensate drain |
| Manually rotating | |
| H | Semi-automatic |
Typcode zur Katalognummer FRC,
FRC-1/4-DB-MINI-
| 001 | Series |
|---|---|
| FRC | Service unit |
| 002 | Pneumatic connection |
| 1/4 | Female thread G1/4 |
| 003 | Version |
| DB | D series, polymer |
| 004 | Pressure regulation range |
| 0.5 ... 12 bar (0.05 ... 1.2 MPa) | |
| 7 | 0.5 ... 7 bar (0.05 ... 0.7 MPa) |
| 005 | Size |
|---|---|
| MINI | Grid dimension 40 mm (without connecting plates) |
| 006 | Service unit combination |
| KA | Filter regulator, branching module and lubricator |
| KC | Manually operated on/off valve, fi lter regulator, branching mod- ule and lubricator |
| 007 | Display unit |
| Bar/psi/without | |
| MPA | MPa |
Typcode zur Katalognummer FRC,
FRC- -D-
| 001 | Series |
|---|---|
| FRC | Service unit |
| 002 | Pneumatic connection |
| 1/8 | Female thread G1/8 |
| 1/4 | Female thread G1/4 |
| 3/8 | Female thread G3/8 |
| 1/2 | Female thread G1/2 |
| 3/4 | Female thread G3/4 |
| 003 | Version |
| D | D series, metal |
| 004 | Size |
| MINI | Grid dimension 40 mm (without connecting plates) |
| MIDI | Grid dimension 55 mm (without connecting plates) |
| MAXI | Grid dimension 66 mm (without connecting plates) |
| 005 | Service unit combination |
|---|---|
| KA | Filter regulator, branching module and lubricator |
| KC | Manually operated on/off valve, fi lter regulator, branching mod- ule and lubricator |
| KB | Filter regulator, branching module with pressure switch and lu- bricator |
| KE | Filter regulator, lubricator, on/off valve electrically actuated, 24 |
| V DC, soft-start valve pneumatically actuated | |
| KF | On/off valve manually operated, fi lter regulator, lubricator, on/ off valve electrically actuated, 24 V DC, soft-start valve pneu- matically actuated, branching module with pressure switch |
| 006 | Condensate drain |
| A | Fully automatic |
| Manually rotating |
