| Hinweis zum Betriebs-/Steuermedium | No acetylene No oxygen | ||
| Werkstoff Schrauben | Steel | ||
| Werkstoff Sichtscheibe | PMMA | ||
| Material screw-in stud | Brass | ||
| Anschlusslage | Centred, rear side | ||
| Mediumstemperatur | -20 °C ... 80 °C | ||
| Measurement accuracy class | 1,60 | ||
| Alternating load factor | 0,9 | ||
| Betriebsmedium | Liquid media Gaseous media | ||
| Explosionsschutz | The information in the certificate must be observed! Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) | ||
| Entspricht Norm | EN 837-3 | ||
| Anzeigebereich | 0 psi ... 3,6 psi |
| Produktgewicht | 120 g | ||
| Material mounting ring | Steel | ||
| Werkstoff Gehäuse | Steel | ||
| Pneumatischer Anschluss | G1/4 | ||
| Umgebungstemperatur | -20 °C ... 60 °C | ||
| Schutzart | IP43 | ||
| Continuous load factor | 0,75 | ||
| Betriebsdruck | 0 bar ... 0,25 bar | ||
| Befestigungsart | Front panel mounting | ||
| Nominal size of pressure gauge | 63 | ||
| Symbol | 00991463 |
