| body | zinc | ||
| bowl type | polymer | ||
| Ablauftyp | automatic drain | ||
| filter element | sintered polypropylene | ||
| flow flow dm3sec | 28 dm3/sec | ||
| maximum inlet pressure imperial pressure psi | 145 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -34 ... 50 °c | ||
| Anschlussgröße | g1/4 | ||
| range | f72g | ||
| retrieve price | true | ||
| service life indicator | with |
| bowl | polycarbonate | ||
| cadfilestep | norgren-f72g-2xd-alx.step | ||
| elastomers | neoprene | ||
| filter element m particlesize micron | 5 μm | ||
| flow flow dm3secbar | 28 dm3/(s.bar) dm3/sec | ||
| maximum inlet pressure pressure bar | 10 bar | ||
| operating temperature f temperature fahrenheit min to max range | -29 ... 122 °f | ||
| partially replaced part | f82g-2gn-ap1 | ||
| product style | modular | ||
| replaced flag | yes | ||
| Baureihe | excelon |
