| connection thread lubrication | M10x1 | ||
| Outside diameter bearing | D | 72 | mm |
| Distance shaft axis | h | 48,50 | mm |
| Size of fixing screws | s | M12 |
| Thickness of flange | c | 12 | mm |
| distance flange to bearing seat | g4 | 17 | mm |
| pich circle diameter fixing holes | m | 130 | mm |
| Shaft diameter | d | 30 | mm |
| Height flange | h1 | 130 | mm |
| number of fastening holes | 3 |
| Flange width | a | 145 | mm |
| Total width with cover | g2 | 57 | mm |
