| Baureihe | ex600-ed2 | ||
| input specifications - power supply for control/input | 24 vdc ?10% max. supply current 2 a | ||
| environmental resistance - enclosure | ip67 (manifold assembly) | ||
| environmental resistance - operating humidity range | 35 to 85% rh (no dew condensation) | ||
| environmental resistance - insulation resistance | 500 vdc, 10 m or more between external terminals and fe | ||
| environmental resistance - impact resistance | 147 m/s2 3 times in each direction of x, y and z (during de-energizing) | ||
| mass | 170 g |
| input specifications - power connector | m12 (5 pins) plug | ||
| input specifications - power supply for output | 24 vdc +10%/?5% max. supply current 2 a | ||
| environmental resistance - operating temperature range | ?10 to 50c | ||
| environmental resistance - withstand voltage | 500 vac for 1 minute between external terminals and fe | ||
| environmental resistance - vibration resistance | 10 to 57 hz with constant amplitude of 0.75 mm p-p 57 to 150 hz with constant acceleration of 49 m/s2for 2 hours in each direction of x, y and z direction (during de-energizing) | ||
| Standards | ce marking, ul (csa) recognition | ||
| Gewicht | .59284 lb |
