FESTO 1120754 Schlittenbaugruppe

ELGR-TB-45

180,58 € 361,16 € -50%
Begrenzter Lagerbestand nur auf Anfrage erhältlich

Technische Daten

Baureihe (ELGR) Linear axis
Drive system (TB) Toothed belt
Führung Recirculating ball bearing guide
Baugröße (45) 45
Stroke [mm] None
Stroke reserve [mm] None
Slide design Standard
Additional slide None
Motor type Without motor
Measuring unit None
Brake None
Cable outlet direction None
Motor position Standard
Proximity sensor, inductive, slot 8, PNP, N/C contact, cable 7.5 m [units] None
Proximity sensor, inductive, slot 8, PNP, N/O contact, cable 7.5 m [units] None
Mounting slot cover, 2x, 500 mm [units] None
Slot nut for mounting slot [units] None
Drive shaft [units] None
Profile mounting None
Operating instructions With operating instructions
Effective diameter of drive pinion 24,83 mm
Baugröße 45
Toothed-belt pitch 3 mm
Führung Plain-bearing guide Recirculating ball bearing guide
Type of motor Stepper motor Servo motor
Max. acceleration 50 m/s²
Wiederholgenauigkeit ±0.1 mm
Schutzart IP20
2nd moment of area Iy 15.700 mm⁴
Max. drive torque 1,24 Nm
Max. Kraft Fz 100 N
Max. feed force Fx 100 N
Mass moment of inertia JH per metre of stroke 0,11 kgcm²
Feed constant 78 mm/U
Zuschlag bewegte Masse pro 10 mm Hub 0,69 g
Gewichtszuschlag pro 10 mm Hub 50 g
Werkstoff-Hinweis Contains paint-wetting impairment substances RoHS-compliant
Material pulleys High-alloy stainless steel
Material toothed belt clamping piece Beryllium bronze
Working stroke 50 mm ... 1.000 mm
Toothed-belt stretch 0,08 %
Einbaulage optional
Konstruktiver Aufbau Electromechanical linear axis With toothed belt
Symbol 991.212
Max. Geschwindigkeit 1 m/s ... 3 m/s
Einschaltdauer 100%
Umgebungstemperatur -10 °C ... 50 °C
2nd moment of area Iz 17.940 mm⁴
Max. Kraft Fy 100 N
Max. idle running transfer resistance 16,1 N
Leerlaufantriebsmoment 0,2 Nm
Mass moment of inertia JL per kg of working load 1,54 kgcm²
Reference value operational performance 5.000 km
Grundgewicht bei 0 mm Hub 3.230 g
Material profile Wrought aluminium alloy Anodised
Material drive cover Wrought aluminium alloy Anodised
Material slide Wrought aluminium alloy Anodised
Material toothed belt Polychloroprene with glass filament and nylon coating
180,58 €
Lagerbestand Angebot anfordern
Teilenummer 1120754
Hersteller FESTO
Menge Stückpreis
1+ 180,58 €
