FESTO EGSS
16 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO EGSS – Electric slide drive. Finden Sie das passende Produkt durch Filtern mit Baugröße, Stroke [mm] und Spindle pitch.
EGSS Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| EGSS | EGSS-BS-KF- - - -ST-M-H1- -AA | Electric slide drive |
Typcode zur Katalognummer EGSS,
EGSS-BS-KF- - - -ST-M-H1- -AA
| 001 | Series |
|---|---|
| EGSS | Electric slide drive |
| 002 | Drive system |
| BS | Ball screw drive |
| 003 | Guide |
| KF | Recirculating ball bearing guide |
| 004 | Size |
| 32 | 32 |
| 45 | 45 |
| 60 | 60 |
| 005 | Stroke [mm] |
| 25 | 25 |
| 50 | 50 |
| 75 | 75 |
| 100 | 100 |
| 125 | 125 |
| 150 | 150 |
| 200 | 200 |
| 006 | Spindle pitch |
| 8P | 8 mm |
| 10P | 10 mm |
| 12P | 12 mm |
| 007 | Motor type |
| ST | Stepper motor ST |
| 008 | Controller |
|---|---|
| M | Integrated |
| 009 | Control panel |
| H1 | Integrated |
| 010 | Bus protocol/activation |
| PLK | PNP and IO-Link® |
| NLK | NPN and IO-Link® |
| 011 | End-position sensing |
| AA | With integrated end-position sensing |
| 012 | Cable outlet direction |
| Standard | |
| D | Underneath |
| L | Left |
| R | Right |
| 013 | Motor attachment position |
| Standard | |
| PL | Parallel, left |
| PR | Parallel, right |
| PD | Parallel, bottom |
| PT | Parallel, top |
| 014 | Electrical accessories |
| None | |
| L1 | Adapter for operation as IO-Link® device |
