DSNU Festo

FESTO DSNU

1806 Produkte

Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO DSNU – Round cylinder, double-acting, based on ISO 6432. Finden Sie das passende Produkt durch Filtern mit Piston diameter [mm], Stroke [mm], Clamping unit, Dämpfung, Cylinder end cap, Protection against rotation, Piston rod type, Piston rod thread extension, Piston rod thread type, Custom thread, Piston rod extension, Temperature range, Constant motion, Corrosion protection, Scraper variant und EU certification.

DSNU Typcodes

Serie	Katalognummernformat	Beschreibung
DSNU	DSNU- - - -A	Round cylinder, double-acting, based on ISO 6432
DSNU	DSNU-S- - - -A	Round cylinder, double-acting, based on ISO 6432

Typcode zur Katalognummer DSNU, DSNU- - - -A

001	Series
DSNU	Round cylinder, double-acting, based on ISO 6432
002	Piston diameter [mm]
8	8
10	10
12	12
16	16
20	20
25	25
32	32
40	40
50	50
63	63
003	Stroke [mm]
...	1 ... 500
015	Clamping unit
	None
KP	attached
004	Cushioning
P	Elastic cushioning rings/plates on both sides
PPS	Pneumatic cushioning, self-adjusting at both ends
PPV	Pneumatic cushioning, adjustable at both ends
005	Position sensing
A	For proximity sensor
006	Special material properties
	None
F1A	Recommended for production facilities for the manufacture of lithium-ion batteries (Cu
007	Cylinder end cap
	Standard
MA	Axial air connection, end cap
MH	Direct mounting, bearing cap
MQ	Transverse supply port, end cap
008	Protection against rotation
Q	Square piston rod
	None
009	Piston rod type

010	Piston rod thread extension
	At one end
S2	Through piston rod
	None
...K2	1 ... 70 mm
011	K6 - Shortened male piston rod thread
	None
K6	1 ... 10 mm
012	Piston rod thread type
	Male thread
K3	Female thread
013	Custom thread
	None
“M10”K5	M10
“M12”K5	M12
“M16”K5	M16
014	Piston rod extension
	None
...K8	1 ... 500 mm
016	Temperature range
	Standard
S6	Heat-resistant seals max. 120 °C
017	Constant motion
	Standard
S10	Uniform, slow movement
018	Corrosion protection
	Standard
R3	High corrosion protection
019	Scraper variant
	Standard
R8	Dust protection
A6	Metal scraper
020	EU certification
	None
EX4	II 2GD

Typcode zur Katalognummer DSNU, DSNU-S- - - -A

001	Series
DSNU	Round cylinder, double-acting, based on ISO 6432
002	Design type
S	Short
003	Piston diameter [mm]
8	8
12	12
16	16
20	20
25	25
004	Stroke [mm]
...	1 ... 200
005	Cushioning
PPS	Pneumatic cushioning, self-adjusting at both ends
P	Elastic cushioning rings/plates on both sides
006	Position sensing
A	For proximity sensor
007	Special material properties
	None
F1A	Recommended for production facilities for the manufacture of lithium-ion batteries

008	Cylinder end cap
	Undefined
MA	Axial air connection, end cap
MQ	Transverse supply port, end cap
MX	Mounting thread, end cap
MP	Swivel mounting, end cap
009	Piston rod thread extension
	None
K2	1 ... 35 mm
010	Piston rod thread type
	Male thread
K3	With female thread
011	K6 - Shortened male piston rod thread
	None
K6	1 ... 8 mm
012	Piston rod extension
	None
...K8	1 ... 150 mm

Produkte

Zeige 1 Produkt bis 12 von insgesamt 1806

Katalognummer	Teilenummer	Piston diameter [mm]	Corrosion protection	Scraper variant	EU certification
DSNU-8-10-KP-P-A	193986	8	Standard	Standard	None
DSNU-8-10-P-A	19177	8	Standard	Standard	None
DSNU-8-10-P-A-CS	8101250	8	Standard	Standard	None
DSNU-8-10-P-A-MQ	193986	8	Standard	Standard	None
DSNU-8-10-P-A-S2	193986	8	Standard	Standard	None
DSNU-8-10-P-A-S6	193986	8	Standard	Standard	None
DSNU-8-15-KP-P-A	193986	8	Standard	Standard	None
DSNU-8-15-P-A	1908247	8	Standard	Standard	None
DSNU-8-20-KP-P-A	193986	8	Standard	Standard	None
DSNU-8-20-P-A	1908248	8	Standard	Standard	None
DSNU-8-25-KP-P-A	193986	8	Standard	Standard	None
DSNU-8-25-P-A	19178	8	Standard	Standard	None
