PARKER DSL102CT

Name: DSL102CT PARKER
Brand: PARKER
SKU: 805046-de-eur
Price: 256.92 EUR
Availability: SoldOut

256,92 € ~~513,84 €~~ -50%

Begrenzter Lagerbestand nur auf Anfrage erhältlich

Technische Daten

max. Druck	3600 psi, 250 bar
Max. Volumenstrom	8 gal/min, 30 l/min

Dichtung	d-ring
Gewicht	180g

Gewicht		0.4 lb, 0.18 kg
Input voltage		85% of rated voltage at 72°f (20°c) min
Minimale Betriebstemperatur		-35 °f, -37 °c
Betriebstemperatur		-35 to +200 °f, -37 to +93 °c
installation torque		37-41 lb-ft, 50-56 nm
filter efficiency rating		iso 4406 18/16/13, sae class 4
for fluid type		mineral-based or synthetic hydraulic fluids
Funktion		2-way
leak rate		120 cc/min @ 3600 psi (250 bar) cm3/min
operation type		solenoid operated, manually operated
maximum flow rate		8 gal/min, 30 l/min
wire mesh screen included		no
actuation type		electrical, manual
maximum inlet pressure rating		3600 psi, 250 bar

response time		30 ms
coil type		5/8" super coil
Maximale Betriebstemperatur		+200 °f, +93 °c
coil nut tightening torque		5-7 lb-ft, 7-10 nm
valve material		all parts steel. all operating parts hardened steel
maximum kinematic viscosity		45-2000 ssu (6 to 420 cst)
override functionality		push and twist
cavity size		c10-2
maximum operating pressure		3600 psi, 250 bar
Mounting type		screw in cartridge valve
division		hydraulic cartridge systems division
seal material		d-ring
configuration		normally closed
flow rate		8 gal/min, 30 l/min
