FESTO DFM

1103 Produkte

Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO DFM – Guided drive, double-acting. Finden Sie das passende Produkt durch Filtern mit Piston diameter [mm], Stroke [mm], Generation, Dämpfung, Position sensing, Führung, Special material properties, Temperature range, Precision adjustment extended und Precision adjustment retracting.

DFM Typcodes

Serie	Katalognummernformat	Beschreibung
DFM	DFM- -	Guided drive, double-acting

Typcode zur Katalognummer DFM, DFM- -

001	Series
DFM	Guided drive, double-acting
002	Piston diameter [mm]
6	6
10	10
12	12
16	16
20	20
25	25
32	32
40	40
50	50
63	63
80	80
100	100
003	Stroke [mm]
...	10 ... 400
004	Generation
	Standard
B	Function-optimised
005	Cushioning
P	Elastic cushioning rings/plates on both sides
PPV	Pneumatic cushioning, adjustable at both ends
YSRW	Shock absorber, self-adjusting, progressive
	Undefined
006	Position sensing
	None

007	Guide
A	For proximity sensor
GF	Plain bearing
KF	Recirculating ball bearing guide
	Undefined
008	Special material properties
	None
F1A	Recommended for production facilities for the manufacture of lithium-ion batteries
009	Temperature range
	Standard
S6	Heat-resistant seals max. 120 °C
010	Precision adjustment extended
	None
AJ	Precision adjustment in the end positions, advancing
011	Precision adjustment retracting
	None
EJ	Precision adjustment in the end positions, retracting
012	Slot cover, sensor slot
	None
...S	1 ... 10 pieces
013	Proximity switch, with cable, 2.5 m
	None
...G	1 ... 10 pieces
014	Proximity switch, contactless, with cable, 2.5 m
	None
...I	1 ... 10 pieces

Produkte

Zeige 1 Produkt bis 12 von insgesamt 1103

Katalognummer	Teilenummer	Piston diameter [mm]	Position sensing	Temperature range	Precision adjustment retracting
DFM-6-5-P-A-GF	4149944	6	For proximity sensor	Standard	None
DFM-6-10-P-A-GF	4149945	6	For proximity sensor	Standard	None
DFM-6-15-P-A-GF	4149946	6	For proximity sensor	Standard	None
DFM-6-20-P-A-GF	4149947	6	For proximity sensor	Standard	None
DFM-10-5-P-A-GF	4154768	10	For proximity sensor	Standard	None
DFM-10-10-P-A-GF	4154769	10	For proximity sensor	Standard	None
DFM-10-15-P-A-GF	4154770	10	For proximity sensor	Standard	None
DFM-10-20-P-A-GF	4154799	10	For proximity sensor	Standard	None
DFM-12-10-B-GF	663349	12	None	Standard	None
DFM-12-10-B-GF	3057123	12	None	Standard	None
DFM-12-10-B-KF	663360	12	None	Standard	None
DFM-12-10-B-KF	8121027	12	None	Standard	None
