| Werkstoff Kolben | Steel | ||
| Werkstoff Gehäuse | Steel | ||
| Werkstoff Dichtungen | NBR TPE-U(PU) | ||
| Release connection, clamping unit | G1/8 | ||
| Produktgewicht | 1.483 g | ||
| Umgebungstemperatur | -20 °C ... 80 °C | ||
| Korrosionsbeständigkeitsklasse KBK | 1 - Low corrosion stress | ||
| Zertifikat ausstellende Stelle | German Technical Control Board (TÜV) CA 697 | ||
| CE-Zeichen (siehe Konformitätserklärung) | To EC Machinery Directive | ||
| Round material to be clamped | 16 mm | ||
| Max. permissible test pressure | 8 bar | ||
| Performance Level (PL) | Stopping, holding, blocking a movement/category 1, Performance Level c | ||
| Positionserkennung | Via proximity switch | ||
| Type of clamping with direction of action | on both sides Clamping via spring force, air to release |
| Material clamp jaws | Tool steel | ||
| Werkstoff Feder | High-alloy steel | ||
| Werkstoff-Hinweis | RoHS-compliant | ||
| Befestigungsart | Via female thread With accessories | ||
| Static holding force | 1.350 N | ||
| LABS-Konformität | VDMA24364-B2-L | ||
| Betriebsmedium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| CE marking (see declaration of conformity) | To UK EX instructions To UK regulations for machines | ||
| Zulassung | German Technical Control Board (TÜV) | ||
| Min. release pressure | 3,8 bar | ||
| Betriebsdruck | 3,8 bar ... 8 bar | ||
| Sicherheitsfunktion | Holding and stopping a movement | ||
| Symbol | 00992086 | ||
| Einbaulage | optional |
