| Material air reservoir | High-alloy stainless steel | ||
| Pneumatischer Anschluss | G1 | ||
| Befestigungsart | With through-hole | ||
| Max. tightening torque for condensate drain | 27 Nm | ||
| Umgebungstemperatur | -10 °C ... 100 °C | ||
| Lebensmitteltauglichkeit | See supplementary material information | ||
| Korrosionsbeständigkeitsklasse KBK | 3 - high corrosion stress | ||
| Zertifikat ausstellende Stelle | CRN0H15669.5C | ||
| CE-Zeichen (siehe Konformitätserklärung) | In accordance with EU Pressure Equipment Directive | ||
| Betriebsdruck | -13,78 psi ... 232 psi | ||
| Entspricht Norm | AD 2000 | ||
| Volumen | 5 l |
| Werkstoff-Hinweis | RoHS-compliant | ||
| Condensate drain connection | G3/8 | ||
| Produktgewicht | 3.581 g | ||
| Max. Anziehdrehmoment Anschlussgewinde | 130 Nm | ||
| Mediumstemperatur | -10 °C ... 100 °C | ||
| LABS-Konformität | VDMA24364-B1/B2-L | ||
| Betriebsmedium | Compressed air to ISO 8573-1:2010 [-:-:-] Nitrogen | ||
| CE marking (see declaration of conformity) | to UK Pressure Equipment Regulations | ||
| Zulassung | CRN German Technical Control Board (TÜV) | ||
| Symbol | 00991474 | ||
| Einbaulage | Condensate drain underneath |
