FESTO CPE
389 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO CPE – Solenoid valve, Compact Performance. Finden Sie das passende Produkt durch Filtern mit Breite, Nominal operating voltage, Elektrischer Anschluss, Ventilfunktion, Pilot air, Pneumatischer Anschluss und Generation.
CPE Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| CPE | CPE- - - - | Solenoid valve, Compact Performance |
Typcode zur Katalognummer CPE,
CPE- - - -
| 001 | Series |
|---|---|
| CPE | Solenoid valve, Compact Performance |
| 002 | Width |
| 10 | 10 mm |
| 14 | 14 mm |
| 18 | 18 mm |
| 24 | 24 mm |
| 003 | Nominal operating voltage |
| None | |
| M1 | 24 V DC |
| M2 | 110 V AC |
| M3 | 230 V AC |
| 004 | Electrical connection |
| BH | Plug pattern ZC |
| CH | Plug M8x1 |
| H | Plug pattern ZC |
| P1 | Interface for pilot valve size 15 mm to ISO 15218 (CNOMO) |
| 005 | Valve function |
| 5L | 5/2-way valve, monostable |
| 5J | 5/2-way valve, bistable |
| 3GL | 3/2-way valve, normally closed |
| 3OL | 3/2-way valve, normally open |
| 5/3G | 5/3-way valve, mid-position closed |
| 5/3E | 5/3-way valve, mid-position exhausted |
| 5/3B | 5/3-way valve, mid-position pressurised |
| 006 | Pilot air |
|---|---|
| Internal | |
| S | External |
| 007 | Pneumatic connection |
| 1/4 | G1/4 |
| 1/8 | G1/8 |
| 3/8 | G3/8 |
| M5 | M5 |
| M7 | M7 |
| QS-4 | Push-in connector 4 mm |
| QS-6 | Push-in connector 6 mm |
| QS-8 | Push-in connector 8 mm |
| QS-10 | Push-in connector 10 mm |
| QS-12 | Push-in connector 12 mm |
| 008 | Generation |
| None | |
| B | Series B |
